zsviczian/obsidian-excalidraw-plugin 2.23.4 on GitHub

New

Added session-scoped AI usage metering with per-model token/image tracking, a new "Session token usage" settings button with Markdown export, and an "AI Usage: input/output" button in ExcaliAI next to Run for quick access to the same breakdown.
Added an explicit opt-in for executing cmd:// links from drawings. Command links are now blocked by default, with a security warning prompt on first use and a dedicated setting under Excalidraw Automate.
Replaced the dropped-link title resolver from Iframely with an HTTPS oEmbed endpoint.
Hardened data URL embeddables: HTML loaded through data:text/html now renders in a sandboxed iframe with a defensive CSP to keep interactive content contained inside the embeddable.

Fixed

Fixed Taskbone OCR, which broke in 2.23.0.
Fixed inline link suggester in MindMap Builder failing when filenames included the "." (dot) character. #2772

New in ExcalidrawAutomate

Added getPathForImageFileId(fileId: FileId): string | null — returns the vault path for an image element identified by its Excalidraw fileId. Note: Excalidraw does not maintain a persistent index of fileIds to paths; the path is only available for images that have appeared in an open drawing during the current Obsidian session.
Gemini image models now expose provider-correct size presets in AI settings and ExcaliAI, with Google image requests automatically translating presets into Gemini aspect ratio and image size parameters.
Added three new ExcalidrawAutomate methods for AI token usage.

/**
 * Returns accumulated AI token usage for the current Obsidian session.
 * Usage is keyed by model identifier. Data is not persisted and resets on restart.
 */
public getAIUsage(): AIUsageData;

/**
 * Opens a modal showing per-model AI token usage for the current session.
 * Includes a "Copy as Markdown" button.
 */
public showAIUsageModal(): void;

/**
 * Returns a compact label string: "AI Usage: 355k/23k" (input/output tokens).
 * Appends image generation count when present, e.g. "+ 3 imgs".
 */
public formatAIUsageLabel(): string;

/**
 * Returns the vault path for an image file identified by its Excalidraw fileId.
 * Only available for images seen in an open drawing during the current session.
 * @param {FileId} fileId - The Excalidraw fileId of the image.
 * @returns {string | null} The vault path, or null if not cached in this session.
 */
getPathForImageFileId(fileId: FileId): string | null;
